C1200 Series Specifications
| Item | Value |
|---|---|
| Kit Prices Excl. GST | |
| Cab | POA |
| Length Hull | 11.99 m |
| Length Overall | 12.74 m |
| Beam Moulded | 4.49 m |
| Beam Overall | 4.54 m |
| Depth Amidships | 2.30 m |
| Hull Draft Max | 0.62 m |
| Max Power | 2 x 425 hp |
| Max Weight | 2 x 480 kg |
| Recommended Power | 2 x 350-400 hp |
| Effective Deadrise at CG | 18 deg |
| Fuel Tank | 4 x 600 litres |
| Fresh Water | 300 litres |
| Sullage | 300 litres |
| Person Capacity | 12 |
| Deck Drainage | Self-draining |
| Plate Thickness | |
| Bottom | 6 mm |
| Sides | 4 mm |
| Decks | 4 mm |
| Cabin | 3 & 4 mm |
The C1200 is the largest vessel in the Sherwood Marine kit range - an 11.99 metre aluminium catamaran offered as the C1200 cab, with pricing on application.
The hulls are 11.99 m long with a 12.74 m overall length on a 4.49 m beam. Plate is 6 mm on the bottom, 4 mm sides, 4 mm decks and 3 and 4 mm cabin. Deadrise at the centre of gravity is 18 degrees and the deck is self-draining. Fuel capacity is 2 x 1,000 litres for 2,000 litres total, and person capacity is twelve. Power is twin outboards to 425 hp each, with 2 x 350 to 400 hp recommended and a 480 kg per-engine weight limit.
Developed from our commercial range, with bow height and tunnel clearance to suit, it also provides excellent interior volume for pleasure boat or charter use, with berths for 5 below deck, and a convertible dinette in the saloon.
