Designs
Recent Projects
20m Patrol Vessel
20m Fisheries Patrol Vessel – Full Design:
Length: 19.99m
Beam: 5.50m
Draft: 1.36m
Crew: 2 […]
36m Motor Yacht Conversion
Added superstructure tier.
Conversion of open sundeck area into enclosed sky-lounge and flybridge. Detailed structural design […]
82m M/Y – Hull Scan and Digital Glass Tempates
Digital Templates for Hull Glazing – Shipset
Optical laser scan of finished (faired) vessel hull openings. […]
13m Flybridge Cruiser – Dynamic Stability Investigation
Dynamic Stability Investigation
The vessel was suffering sudden and uncontrollable broaches in relatively benign sea conditions. […]
64m Motor Yacht – Gyro Installation
Preliminary structural design for dual (“stacked”) gyro-stabiliser installation. Aluminium hull vessel with steel subframe for […]
2 x 5m RIB Patrol / Workboats
Design and construction of 2 x 5m RIB patrol / workboats. Level floatation (swamped) design […]
